Leader LV5490 Monitor Selected For Coverage Of FIFA World Cup

Leader's LV5490 4K/HDR multiscreen waveform monitor has been deployed as a master reference test instrument for 4K UHD coverage of the 2018 FIFA World Cup in Russia.

Several of European broadcasters organisations selected the monitor.

"The LV5490 has established itself as the preferred choice of many broadcasters and major OB companies covering large scale events such as the current football tournaments from Russia," said Leader's European Regional Development Manager, Kevin Salvidge.

"LV5490 instruments were fielded at the beginning of the year for one of the biggest OB projects in the 2018 sports calendar, also at the UHD-HDR Bundesliga tests in Germany and most recently for broadcast coverage of a major-league football final from the NSC Olimpiyskiy stadium in Kiev.

"4K coverage of the latest tournament commenced with the opening match which saw Russia's five-nil win against Saudi Arabia at the Moscow Luzhniki stadium.

"A total of 28 games will be covered in 4K, up to and including the final on July 15. UHD transmissions are being carried by a number of broadcasters and telco providers on dedicated 4K feeds as well as via satellite."

Leader's LV5490 offers 4K, UHD, 3G, HD and SD test and measurement features in a half-rack-width by 4U portable unit with a high definition 9 inch front-panel monitor. It provides all the capabilities needed to implement the full potential of high dynamic range in both HD and UHD.

Signal displays such as video waveform, chroma levels, colour vectors, bar graphs, noise, video patterns, quad 3G phase, data tables, camera picture output, colour chart, multichannel audio levels and surround sound vectors can be viewed simultaneously in a user customisable layout. If a specific element requires detailed attention, this can be selected quickly for viewing at higher resolution or full screen.

The LV5490 supports preconfigured settings to ensure the reference levels are correct for both HLG and Dolby PQ production. A 75% HLG or 58% PQ marker is also displayed automatically on the waveform monitor graticule. This represents the reference level, enabling the vision engineer to ensure that any object placed at the centre of interest within a scene occupies the appropriate signal range and that sufficient headroom is reserved for specular highlights.

Another recently added feature is system gamma optical transfer function capability for HLG and Sony 'SR-Live for HDR' workflow.

The Leader CINELITE HDR toolset also comes as a standard feature of the LV5490, allowing easy assessment of relative exposure and overall luminance during production. A focus-assist option allows highly accurate on-set adjustment of camera focus to match the ability of 4K and UHD formats to handle very precise image detail.

Supplementing its front-panel display, the LV5490 provides 1920 x 1080 HD DVI and HD-SDI feeds for connection to external monitors. Simultaneous viewing of up to four 3 gigabit/s SDI inputs is possible, including overlays. The size and location of individual channels can be adjusted on the display using a USB pointer so the user is not limited to fixed-size quadrants. Operators can select the size and position of the measuring area as well as the Y/G/B/R component channel. An alarm can be set to alert operators if the noise level exceeds a predefined threshold. An integral low-pass filter allows elements of the high frequency band to be removed at the time of noise measurement.
